Hiace Interior Height & Wheel Arch Measurements

(Crucial for Layout Planning & Bed Builds)

Understanding the Toyota Hiace interior dimensions is one of the most critical steps when designing a DIY camper kit for Hiace. Interior height and wheel arch measurements directly affect bed height, storage layout, kitchen positioning, and overall comfort.

Whether you’re planning a simple weekend camper or a full-time touring setup across NSW & QLD, these measurements help you avoid costly mistakes during your build.

Toyota Hiace Interior Height (Approximate)

Interior height varies depending on model year, roof type, and market (Australian vs Japanese import).

Standard Roof Hiace

• Interior height: ~1,320 – 1,350 mm

• Best for:

  • Low-profile bed platforms

  • Minimal cabinetry

  • Budget DIY camper kits

High Roof Hiace (Japanese Import)

• Interior height: ~1,600 – 1,650 mm

• Best for:

  • Standing room (partial to full)

  • Overhead storage

  • Long-term camper builds

💡 Tip: If standing height matters, Japanese import Hiace vans are often the best value option in Australia.

Explore available models here:
👉 https://commercialmotorgroup.com.au/toyota-hiace.html

Wheel Arch Measurements – Why They Matter

Wheel arches are the main obstacle when building beds and storage systems inside a Hiace.

Typical Hiace Wheel Arch Dimensions

• Width (outside to outside): ~1,250 – 1,280 mm

• Height from floor: ~300 – 320 mm

• Arch depth (front to back): ~250 – 300 mm

These dimensions determine:

• Minimum bed platform height

• Drawer clearance

• Under-bed storage capacity

Bed Build Height Calculations (Practical Example)

If your wheel arch height is 310 mm, then:

• Minimum bed platform height: 330 – 350 mm

• Comfortable mattress thickness: 80 – 120 mm

➡️ Resulting bed height: ~420 – 470 mm

This still leaves enough headroom in:

• High roof Hiace models

• Smart low-profile DIY camper layouts

Interior Width for Bed Layouts

Interior width affects whether you can sleep sideways or lengthways.

Hiace Interior Width

• Wall to wall: ~1,550 – 1,600 mm

• Between wheel arches: ~1,250 mm

Sleeping options:

• Sideways bed: Shorter sleepers (under 170 cm)

• Lengthways bed: Best for comfort & tall travelers

Many DIY builders use extendable bed systems to maximize space.

Ideal Layout Based on Dimensions

Compact Weekend Layout

• Bed height: ~350 mm

• Storage: Soft bags & slim drawers

• Kitchen: Slide-out portable unit

Full Touring Camper Layout

• Bed height: ~450 mm

• Storage: Full drawer system

• Kitchen: Fixed cabinet + sink

• Power: Dual battery + solar

For layout inspiration, watch real Hiace builds here:
🎥 https://www.youtube.com/watch?v=XsCpPG2m4VU
🎥 https://www.youtube.com/watch?v=5eab2iWhGMI

Why Dimensions Matter for DIY Camper Kits

Knowing exact Dimensions for Toyota Hiace allows you to:

• Pre-cut timber accurately

• Order the right mattress size

• Design modular DIY camper kits for Hiace

• Avoid re-building costly components

If you’re planning a Hiace 4WD campervan or Hiace 4x4 off-road build, interior efficiency becomes even more important due to added gear.

Buying the Right Hiace for Your Layout

Before starting any build, choosing the right base van saves time and money.

Recommended options:

• Toyota Hiace vans for sale:
  👉 https://commercialmotorgroup.com.au/toyota-hiace-van-for-sale.html

• Campervan-ready models:
  👉 https://commercialmotorgroup.com.au/campervan-for-sale.html

• Commercial vans for DIY conversion:
  👉 https://commercialmotorgroup.com.au/commercial-van-for-sale.html

Commercial Motor Group specializes in Toyota Hiace models suitable for camper conversions across NSW & QLD.
